Productivity

Exceptional Run Times – Work longer with up to two shifts on one battery charge without sacrificing performance, thanks to Cat Lift Trucks 3-phase AC technology and regenerative braking.

• Advanced drive system – no brushes or commutator
• All AC hydraulic system
• Enhanced electric power steering



Adaptable Performance Modes – Optimize your performance and efficiency by simply selecting one of the pre-set operating modes. Profits are maximized by achieving the right balance between output and economy.

Ergonomics

Adjustable Full-Suspension Grammer^® Seat – The full-suspension, standard vinyl seat can be adjusted to give the operator the most comfortable position possible:

• Front and back
• Lumbar support
• Suspension



Optional Fingertip Controls – Effortlessly control the hydraulic function, horn and direction (Forward/Neutral/Reverse) with the optional seat-mounted armrest.

Narrow Steering Column

• Easy to operate
• Tilt-adjustable
• Full-hydrostatic steering

Energy Efficiency

Regenerative Braking – Activated when the lift truck decelerates, changes directions, or service brakes are applied, this feature helps to return energy to the battery. The result is extended run times and extended service brake life.

• Improves battery life
• Reduces brake wear
• Minimizes heat build up



Two-Stage Hydraulic System – Allows these cushion tire lift trucks to provide precise load handling, fast lift speeds and less energy consumption.

Awareness

Operator Presence Detection System – This integrated, computer-based feedback system uses both audible and visual indicators to alert the operator to potentially hazardous situations, while increasing operator awareness.

Highly-Visible Orange Seat Belt – Helps to clearly see when the operators are wearing their seat belt.

Options

Special Application Packages

• Two drive-in rack options to better fit different applications
• Freezer for intermittent use below 14 degrees Fahrenheit



Electronic Back-up “Smart” Alarm

• Ideal option for freezer and cold applications
• Alarm automatically adjusts its volume level to suit the environment



Productivity Options

• Foot direction control
• Steering wheel knob
• Rear grab handles with horn button

More Efficiency, Less Maintenance

The Lithium-ion battery package provides the highest performance battery solution.

• High performance batteries that are synchronized with the lift truck and charger for optimal energy efficiency
• No maintenance requirements and a longer service life mean each truck offers more daily use, increased throughput and reliable 24/7 output
• No more battery change outs, watering and degassing areas
• Maximize truck productivity through opportunity charging that can be interrupted anytime
• 5-year battery warranty included
