Features:
Portable, compact, rugged design
Parker’s exclusive Parkalign system, which positions the fitting in the die for a perfect crimp every time
An efficient bottom-loading design that makes it easier for operators to manage long hose assemblies
Linked dies that prevent segments from being misplaced or mismatched
Dies that are color coded by size for easy identification and reduced set-up time
Durability that provides years of reliable service
An information-rich decal that details the list of proper hose and fitting combinations, tools required and the crimp specification for each hose and fitting combination

Specifications:
Dimensions: 30” high, 12” deep, 15” wide
Weight: 70 lbs. (Base unit without power unit)
Capabilities: 25, 26, 43, 56, 81, CG and HY series (steel) fittings
Set up time: 20 seconds
Full cycle time: 30 seconds with 82C-OEP Power Unit (1/2” 43 Series)
System Pressure: 10,000 PSI maximum, 30 ton force
