The Pro Series 1/2 Gallon Air Hydraulic Pump is specifically designed for automotive, light truck and heavy-duty applications. This pump is constructed with the user in mind, as a compact lightweight air hydraulic pump solution that delivers a powerful punch; requiring only 80 PSI for 10,000 PSI of operating hydraulic pressure to power even the heaviest of cylinders, ram, bead breakers, and more. Built in exhaust muffler promotes safer, quieter operation along with a robust foot pedal providing hand-free pumping and release of load. Manufactured with the highest of quality parts and components designed to withstand rigorous use in any environment. Designed with fully serviceable pump motors, allowing for economical repairs and maintenance. Aluminum reservoir is lightweight, and durable for field, shop and mobile application.

Specifications:
Hydraulic Pressure Rating: 10,000 PSI
Usable Oil Capacity (Cubic In.) 135 cu. in.
Output Flow Rate (Cu. In. Per Min.) :
No Load: 80.5 cu. in.
Load: 12.8 cu. in.
Air Pressure Range: 40-170 PSI
Threaded Connections Sizes: Air Inlet: 1/4"-18 NPT
Hydraulic Hose Inlet: 3/8"-18 NPTF
Dimensions: 12.5 (L) x 5.75 (W) x 8 (H) in.
