Load capacity: 1500 kg. (3307 lbs)
Charging time: 3 hours
Working time: 4 – 6 hours (4 hours continuous)
Drive motor: 0.6 kw
Load center distance: 600 mm (23.62 in)
Fork height, lowered: 80 mm (3.15 in)
Tire size, front: F250 mm (9.84 in)
Tire size, rear: F80 mm (3.15 in)
Max lift height: 110 mm (4.33 in)
Height of tiller in drive position min/max: 635/1200 mm (25/47.24 in)
Overall length: 1693 mm (66.65 in)
Overall width: 685 mm (26.97 in)
Fork dimensions t/w/l: 45/160/1220 mm (1.77/6.30/48.03 in)
Width overall forks: 685 mm (26.97 in)
Aisle width for pallets 1000×1200 crossways: 2294 mm (90.31 in)
Aisle width for pallets 800×1200 lengthways: 2132 mm (83.94 in)
Turning radius: 1494 mm (58.82 in)
Travel speed, loaded/unloaded: 4/4.5 km/h
Max. gradeability, loaded/unloaded: 4/20%
Battery voltage, nominal capacity K: 48V/20aH
Battery weight: 8.5 kg. Battery dimensions l/w/h: 340x130x307 mm (13.39x5.12x12.09 in)
Service weight (with battery): 145 kg
Standard options: Turtle switch for creep speed, battery discharge indicator, EMC certified charger
Please note - BR2748 pallet trucks are not intended to have load backrest retrofitted. For applications that require a backrest, pallet jack part number BR2748B includes a load backrest.
