Load capacity: 1500 kg. (3307 lbs)
Charging time: 3 hours
Working time: 4 – 6 hours (4 hours continuous)
Drive motor: 0.6 kw
Load center distance: 600 mm (23.62 in)
Fork height, lowered: 80 mm (3.15 in)
Tire size, front: F250 mm (9.84 in)
Tire size, rear: F80 mm (3.15 in)
Max lift height: 110 mm (4.33 in)
Height of tiller in drive position min/max: 635/1200 mm (25/47.24 in)
Overall length: 1693 mm (66.65 in)
Overall width: 685 mm (26.97 in)
Fork dimensions t/w/l: 45/160/1220 mm (1.77/6.30/48.03 in)
Width overall forks: 685 mm (26.97 in)
Aisle width for pallets 1000×1200 crossways: 2294 mm (90.31 in)
Aisle width for pallets 800×1200 lengthways: 2132 mm (83.94 in)
Turning radius: 1494 mm (58.82 in)
Travel speed, loaded/unloaded: 4/4.5 km/h
Max. gradeability, loaded/unloaded: 4/20%
Battery voltage, nominal capacity K: 48V/20aH
Battery weight: 8.5 kg. Battery dimensions l/w/h: 340x130x307 mm (13.39x5.12x12.09 in)
Service weight (with battery): 145 kg
Standard options: Turtle switch for creep speed, battery discharge indicator, EMC certified charger
Load backrest and hardware are included in the crate but NOT installed. The bracket is welded to the frame on the TW2748B, which is required for backrest installation. There are two threaded holes on the lower sides of the frame, whereas the TW2748 pallet truck does not have threaded holes.
